Professional Acoustic Imaging Camera

About the product

The MPAC208 is a professional-grade acoustic imaging camera designed for fast, accurate detection of ultrasonic sound sources across industrial environments. It helps maintenance teams identify gas leaks, mechanical deterioration, and partial discharge (PD) in high-voltage electrical systems, without needing to interrupt operations.
At its core is a 208 channel MEMS (micro-electromechanical system) microphone array offering sensitivity across 2 kHz to 100 kHz, enabling the MPAC208 to detect even very small leaks and subtle ultrasonic patterns.
The acoustic data is fused with a 13 MP optical camera and displayed on an 8-inch capacitive touchscreen, presenting clear, real-time visual overlays that make sound sources immediately visible.
The MPAC208-IECEx camera provides all the features seen in the standard MPAC208 but is certified for use in Class 2 explosive atmospheres.
Designed for real industrial environments
With a detection range up to 200 m, the MPAC208 is suitable for both close-proximity inspection and stand-off safety at substations, switchgear, or during overhead line work.
The Focus function suppresses background noise, allowing operators to isolate target sound sources even in loud plants or workshops. SoundScan™ directional guidance assists in locating leaks that are outside the visible frame, helping technicians trace issues quickly

Three core operating modes

• Gas Leak Mode: Automatically estimates leak rate, cost impact, and distance to the source, helping prioritise repairs and quantify energy loss.
• Partial Discharge Mode: Captures PD activity and provides PRPD (Phase Resolved Partial Discharge) analysis, supporting early detection and classification of discharge types.
• Mechanical Mode: Identifies bearing wear, valve leakage, cavitation, and vibration-related wear patterns through ultrasonic signatures.

Megger MPAC208 Datasheet

2500V Insulation Resistance Meter (Digital High-Voltage Megohmmeter)

Key features

• Up to 500 GΩ insulation resistance measurement range
• Fast-measurement design, faster & stable resistance reading, higher efficiency
• Automatic calculation of polarization index (PI) and dielectric absorption ratio (DAR)
• Low power design meets the requirements of high-intensity work: up to 1300 times of 2500 V measurement, and up to 6500 times of 250 V measurements*
• High-safety design with dangerous voltage alarm function, and complies with CAT IV 600V standard and China power industry specifications DLT845
• The new high-reliability design, all specifications are met even under the environment of 50 °C temperature and 80% RH; all probes and corresponding ports are tested for 30,000 mating test

Fluke 1537 adds the following features based-on the above features:

• AC/DC voltage and resistance measurement
• Short-circuit current >5 mA, faster and more accurate
• Fine-tunable test voltage: 250 V to 2500 V,100 V step
• Automatic calculation of dielectric discharge rate (DD), find insulation problems that are not easily detectable in multilayer insulation
• User-defined label, timing test, measurement results storage
• Download data with provided PC software

Fluke 1535/1537 2500V Datasheet

Acoustic Imager

Fluke ii500 Acoustic Imager with LeakQ™: Detect, Locate, and Capture Gas Leaks

The Fluke ii500 Acoustic Imager, equipped with LeakQ™ technology, empowers maintenance teams to detect and locate gas leaks efficiently. Designed for ease of use, it requires no specialized training. Even during peak production periods, teams can effectively identify gas and vacuum leaks. The ii500's advanced acoustic leak detection technology isolates leak sound frequencies, making leaks visible even in noisy environments.

Key Features:

• Ready-to-Use: The Fluke ii500 is ready out of the box. Its rugged, ergonomic design ensures easy handling, while the large 7" LCD display allows for clear leak visualization.
• Quick Detection: Even users with minimal experience can start detecting leaks within minutes. The tool estimates relative leak size and cost, incorporating a new distance-estimation feature and the 1-10 LeakQ™ severity index.
• SoundMap™ Overlay: The 7" LCD touchscreen overlays a SoundMap™ on visual images, facilitating rapid leak location identification.
• Intuitive Interface: Easily isolate leak sound frequencies and filter out background noise.
• Tagging and Organization: Use image and video tagging, annotation, and folders for efficient organization.
• Leak Sizing: Prioritize repairs based on relative leak size.
• Collaboration: The reporting tool allows sharing of visuals, tagging, and notes with team members and repair personnel.

Fluke ii500 Datasheet

Advanced Pro Wire Tracer Kit

Built to Keep You Safe

The Fluke 2062 Advanced Pro Wire Tracer accurately and safely troubleshoots energized and de-energized wires in residential, commercial, and industrial environments up to CAT IV 600 V. This CAT rating offers the highest protection available on any wire tracer. It’s designed to protect you from the most dangerous levels of transient overvoltage, spikes up to 8,000 V, that can occur in industrial and utility environments. This is especially important for scenarios you may encounter in environments like industrial plants, factories, and hospitals where critical equipment cannot be taken offline.

Fluke 2062 Datasheet

NH3|SF6 Gas Optical Thermal Imaging Camera

G640 uses quantum well infrared detector, which can accurately find SF₆INH₃ leakage point through thermal imaging. This portable thermal camera can detect leaks from a safe distance, therefore it can greatly ensure the safety of operators. In addition, it can also track some harmful gases to make contributions to environment.

ULIRVISION G640 Datasheet
