Battery Tester

The BITE5 will test lead acid batteries, NiCD batteries as well as lithium-ion batteries. It will measure and record battery voltage, impedance, and temperature. The recorded data can be trended on the unit’s touch screen. View the trended data of each test or trend the data of each cell. Set pass, warning, and fail limits for voltage and impedance. Record the ripple voltage, ripple current, and float current and transfer the recorded data via USB or via an SD card to the Power DB software, then create custom reports and automated analysis.

The BITE5 can measure impedances on cells up to 200Vdc. Save time by measuring entire banks of cells instead individual cells. Measure lithium ion battery packs.

Product Catalog

We present our solution for mapping and digitalisation campaigns of electric distribution networks! The ILF G2 device will allow you to identify how your subscribers are connected to the Low Voltage network with 100% reliability, integrating the survey results in the company's GIS system thanks to its digitalisation app, GridGIS Connect. Do you want to know more about our solution? Download our catalogue.

Merytronic Portable Devices

Application Note

Electric motors are made up of a multitude of components that when combined and assembled into a motor have to endure extreme electrical and mechanical operating stress as well as varying environmental conditions during their service life. To prevent premature failure, regular testing is necessary to ensure reliable operation and, importantly, to extend the motor’s service life.

Guide to low voltage Motor Testing

Application Note

Self-Powered-Relay (SPR) takes its supply from the  CT-s connected and also the energy for tripping the breaker. SPR  either has special CT made for the relay or is made to be used directly with standard CT-s.

There are differences in how to set Sverker 900 when testing SPR that must be noticed.
1. The level of pre-fault current and time needed for pre-fault.
2. The pickup level for trip signal if not dry contact is used.

Here secondary testing of SEG relay (formerly Woodward) WIP1 and WIC1 will be described.

Application for Testing Self Powered Relays SEG (Woodward) WIP1 and WIC1

TECHNICAL GUIDE

Gain insight into the different types of oil testing methods, including oil dielectric breakdown testing moisture content testing. This guide covers best practices for oil testing, the correct equipment to use, and the different IEEE/IEC standards to adhere to when testing.

Guide to Insulating Oil Dielectric Breakdown Testing – OTS Series

APPLICATION NOTE

Continuous coal and biomass monitoring is an important step in understanding the conditions leading to a fire. Hot spots can flare up devastating spontaneous combustion, potentially causing thousands of dollars in material loss, dangerous work conditions, and difficult extinguishing options. Prevention is becoming readily available with cost-effective continuous thermal image monitoring as a method for early warning.

Using Fixed Thermal Imaging to Identify Dangerous Hot Spots in Coal or Biomass
Thermoview TV40 Datasheet
Thermoview TV40 Brochure
